OptimaFlex Multi-Block Gradient PCR System

The OptimaFlex Multi-Block Gradient PCR System revolutionizes laboratory efficiency by combining high-throughput capabilities with unmatched flexibility. This system offers three interchangeable thermal blocks: 1 x 96-well for 0.2ml tubes, 2x 48-well for 0.2ml tubes and 3 x 32-well for 0.2ml tubes, allowing seamless transitions between different sample volumes and experimental needs. It is designed for researchers who demand precision and adaptability, providing high throughput in parallel operation in combination with the flexibility to run different protocols.
Compare
Add to wishlist
Add to quote
Description

Features

  • Independent Block Operation: Each block operates independently, maximizing experimental efficiency and equipment utilization.
  • Flexible Heated Lid: Automatically adjusts to fit 0.2ml PCR tubes for optimal sealing.
  • Programmable Temperature Gradients: Independently adjustable gradients for optimized annealing conditions.
  • Precise Temperature Control: Utilizes Peltier elements for high accuracy and uniformity.
  • Space-Saving Design: Independent front/rear air ducts enable close instrument placement, saving lab space.
  • User-Friendly Interface: High-resolution 10.1-inch LCD touchscreen for intuitive operation and real-time monitoring.
  • Power Failure Recovery: Automatically resumes interrupted protocols after power restoration.
  • Modular Flexibility: Interchangeable blocks adapt to diverse experimental needs.
Specifications

Specifications

PN PCR96GX1 PCR48GX2 PCR32GX3
Type Single-block Dual-block Triple-block
Sample capacity 1x 96-well x 0.2ml 2 x 48-well x 0.2ml 3x 32-well x 0.2ml
PCR reaction volume 10~100μl
Temperature control mode Block or Tube
Heating lid temperature 30~115℃
Sample temperature range 0℃~100℃
Max. Block ramp rate 5.5℃/s
Max. Sample ramp rate 3℃/s
Temperature accuracy ≤±0.2℃ (block temperature reaching 95℃)
Temperature uniformity ≤±0.2℃ (10s after reaching 95℃)
Maximum temperature

difference between blocks

 5℃
Temperature difference between two adjacent blocks 0.1~5℃
Max. Number of steps 50
Time increment / decrement 1 ~ 120s
Temperature increment / decrement 0.1~10℃
Maximum number of cycles 999
Long-range PCR Yes
Touchdown PCR Yes
Display 10.1-inch LCD touch screen (resolution 1024×800)
Program storage capacity Up to 100 programs
Communication Interface USB-A
Power-off data protection Yes
Power supply AC100~240V; 50/60Hz; 1000W
Working temperature 10-30℃
Working humidity 20-80% (Non-condensing)
PCR thermal block replacement Easy replacement without any tools



Accessories

Accessories

Applicable Consumables

PCR96GX1 0.2ml tubes, 8-tube strips, 96-well PCR plates (nonskirted/semi-skirted)
PCR48GX2 0.2ml tubes, 8-tube strips
PCR32GX3 0.2ml tubes, 8-tube strips

Accessories

PN Photo Accessory
32GX3 32GX3 3 x 32-well block
48GX2 48GX2 2 x 48-well block
96GX1 96GX1 1 x 96-well block
